Glass LED Cabinet type Glass Media Facade
High Transparency Design for Indoor Installation. Suitable for large mirror buildings. High Brightness allows to have a great view outside of the building. Perfect for boutiques and branded shops. High brightness & low power consumption – while maintaining high brightness of 7500 nit.
Convenient installation – free of steel frame structure, adapt to various types of buildings.
| Parameter | Specification | ||||
| Type | P2.5/5.2 indoor&outdoor | P3.9/7.8 indoor&outdoor | P 7.8 indoor&outdoor | P 10 indoor&outdoor | P15.25 indoor&outdoor |
| Product model | P2.5/5.2 indoor&outdoor | P3.9/7.8 | P 7.8 | P 10 | P 15.25 |
| Pitch(mm) | From left to right 2.5 mm, From top to bottom 5.2 mm | From left to right3.9mm, From top to bottom 7.8mm | 7.8mm | 10.4 mm | 15.25 mm |
| Pixel configuration | 1R1G1B | ||||
| LED Type | SMD 2121/1921 | ||||
| Brightness | 1000cd/m²/5500 cd/m² | ||||
| Brightness control | Manual/Automatic adjustment | ||||
| Color temperature | 6300-9000K | ||||
| Viewing Angle | 140/120 ° | ||||
| Pixel density | 76924 pixel/m² | 32768 pixel/m² | 16395 pixel/m² | 9246 pixel/m² | 6400 pixel/m² |
| Cabinet resolution(W×H) | 400 pixel × 97pixel | 256pixel×64pixel | 128 pixel×64 pixel; 128 pixel×128 pixel | 96 pixel×48 pixel; 96 pixel×96 pixel | 80 pixel×40 pixel; 80 pixel×80 pixel |
| Cabinet size(W×H×D) | 1000×500×72; 1000×1000×100 | ||||
| Weight/cabinet(kg) | 6 kg/15 kg panel | ||||
| Cabinet meterial | Aluminum | ||||
| Cabinet color | White/Silver/ Black | ||||
| Waterproof | Indoor IP 31, Outdoor IP 43 | ||||
| Operate temperature/ humidity | -20℃~+60℃/10%~95% | ||||
| Storage temperature/ humidity | -40℃~+85℃/10%~95% | ||||
| Color processing | ≥16 bits | ||||
| Gray level | 65536 levels per color | ||||
| Color | 16.7M | ||||
| Brightness uniformity | 97%/±0.003 | ||||
| Chrominance uniformity | (x,y)±0.003 | ||||
| Transparence | 35% | 55% | 66% | 82% | 85% |
| Frame-changing frequency | 50/60Hz | ||||
| Refresh rate | ≥1920Hz | ||||
| Power voltage(V) | AC100-240V | ||||
| Max.Power (W/㎡) | 560 W/m² | 500 W/m² | |||
| Average Power (W/㎡) | 185 W/m² | 150 W/m² | |||
| Life time | 100000 hours | ||||
| Scanning | 1/16 scan | ||||
| Drive method | Constant current drive | ||||
| Installation | Fix/Hang | ||||
| Maintenance mode | Front maintenance / Back maintenance | ||||
| Seismic resistance | 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes | ||||
