Slim tab Series 320X160 mm
RM Series is a family of fine pitch LED video wall displays, RM series gives new meaning to multi-functionality and quick installation by offering front serviceability and a creative stackable design that eliminates cabinet-to-cabinet cabling and reduces complexity of installation and vertical alignment
| Parameter | Specification |
| Model Name | Slim Tab P 1.25 320X160mm |
| Pixel Pitch | 1.25 mm |
| Pixel Configuration | SMD 1010 |
| Panel Size | 320*160*45 mm |
| Panel Resolution | 256*256 |
| Panel Weight | 4 kg/unit |
| Pixel per ㎡ | 284440 |
| Brightness | 200-800nits |
| IP Rating (Front/Rear) | Back: IP41, Front: IP41 |
| Fresh Rate | 3000 HZ – on request |
| Max / Avg Power Consumption per m2 | 650/235W/m² |
| Color Processing | 16bit |
| Viewing Angle (H/V) | 160 /160 ° |
| Operating Temperature | -10~45° |
| Main Power Source | AC100-240V; 50/60Hz |
| Humidity | 10~90% RH |
| Life Time | 100000 Hours |
| Maintainance method | Front/ Back service |
